Model:KXZ-130B
Automatic Tray Food Cartoning Machine
Encasing speed: 30-60boxes/min
Quality requirement: 250-450g/m2
Dimension range: (70-250)mm×(50-120)mm×(35-105)mm
| Watch The Video |  |
Encasing speed: 30-60boxes/min
Quality requirement: 250-450g/m2
Dimension range: (70-250)mm×(50-120)mm×(35-105)mm
| Watch The Video | |
Products Description
The KXZ - 130B Automatic Tray Food Cartoning Machine is designed for food tray packaging. It handles fresh fruits, snacks, etc. at 60 trays/min, ensuring fast and accurate packaging with less product damage. Many food firms praise it for boosting productivity.
The KXZ - 130B shines in food processing. In bakery, it swiftly packs bread into trays, ensuring uniform packaging. In frozen food plants, it neatly packages ice cream bars, cutting costs and boosting output.
Products Description
The KXZ - 130B Automatic Tray Food Cartoning Machine is designed for food tray packaging. It handles fresh fruits, snacks, etc. at 60 trays/min, ensuring fast and accurate packaging with less product damage. Many food firms praise it for boosting productivity.
The KXZ - 130B shines in food processing. In bakery, it swiftly packs bread into trays, ensuring uniform packaging. In frozen food plants, it neatly packages ice cream bars, cutting costs and boosting output.
Technical Parameter
|
Encasing Speed |
30-60boxes/min |
|
|
Box |
Quality requirement |
250-450g/m2 (according to its dimension to confirm) |
|
Dimension range (L×W×H) |
(70-250)mm×(50-120)mm×(35-105)mm can customize according to your requirement |
|
|
Compressed air |
Working pressure |
≧0.6mpa |
|
Air consumption |
20m3/h |
|
|
Power supply |
380V 50Hz |
|
|
Motor power |
1.5KW |
|
|
Machine dimension (L×w×H) |
4600*1350*1900mm |
|
|
Machine weight |
1800KGS |
|
Technical Parameter
|
Encasing Speed |
30-60boxes/min |
|
|
Box |
Quality requirement |
250-450g/m2 (according to its dimension to confirm) |
|
Dimension range (L×W×H) |
(70-250)mm×(50-120)mm×(35-105)mm can customize according to your requirement |
|
|
Compressed air |
Working pressure |
≧0.6mpa |
|
Air consumption |
20m3/h |
|
|
Power supply |
380V 50Hz |
|
|
Motor power |
1.5KW |
|
|
Machine dimension (L×w×H) |
4600*1350*1900mm |
|
|
Machine weight |
1800KGS |
|
Standard Features
 |
 |
 |
| Box loader | Output | Porduct loader |
 |
 |
|
| Seal box | Seal box |
Standard Features
|
|
|
| Box loader | Output | Porduct loader |
|
|
|
| Seal box | Seal box |
