Model:KXZ-130B
Automatic Tissue Paper Cartoning Machine
Encasing Speed: 30-60 boxes/min
Box quality requirement: 250-450g/m2
Box dimension range: (70-250)mm×(50-120)mm×(35-105)mm
| Watch The Video |  |
Encasing Speed: 30-60 boxes/min
Box quality requirement: 250-450g/m2
Box dimension range: (70-250)mm×(50-120)mm×(35-105)mm
| Watch The Video | |
Products Description
The KXZ - 130B Automatic Tissue Paper Cartoning Machine is designed for high - speed tissue paper packaging. It features precise paper - folding and carton - filling mechanisms. With a sturdy build, it ensures continuous operation and low error rates compared to similar models.
In large - scale tissue production plants, the KXZ - 130B efficiently packs boxed facial tissues and roll toilet papers. For mid - sized manufacturers, it ensures fast and accurate packaging of travel - sized tissue packs, enhancing productivity.
Products Description
The KXZ - 130B Automatic Tissue Paper Cartoning Machine is designed for high - speed tissue paper packaging. It features precise paper - folding and carton - filling mechanisms. With a sturdy build, it ensures continuous operation and low error rates compared to similar models.
In large - scale tissue production plants, the KXZ - 130B efficiently packs boxed facial tissues and roll toilet papers. For mid - sized manufacturers, it ensures fast and accurate packaging of travel - sized tissue packs, enhancing productivity.
Technical Parameter
|
Encasing Speed |
30-60boxes/min |
|
|
Box |
Quality requirement |
250-450g/m2 (according to its dimension to confirm) |
|
Dimension range (L×W×H) |
(70-250)mm×(50-120)mm×(35-105)mm can customize according to your requirement |
|
|
Compressed air |
Working pressure |
≧0.6mpa |
|
Air consumption |
20m3/h |
|
|
Power supply |
380V 50Hz |
|
|
Motor power |
1.5KW |
|
|
Machine dimension (L×w×H) |
4600*1350*1900mm |
|
|
Machine weight |
1800KGS |
|
Technical Parameter
|
Encasing Speed |
30-60boxes/min |
|
|
Box |
Quality requirement |
250-450g/m2 (according to its dimension to confirm) |
|
Dimension range (L×W×H) |
(70-250)mm×(50-120)mm×(35-105)mm can customize according to your requirement |
|
|
Compressed air |
Working pressure |
≧0.6mpa |
|
Air consumption |
20m3/h |
|
|
Power supply |
380V 50Hz |
|
|
Motor power |
1.5KW |
|
|
Machine dimension (L×w×H) |
4600*1350*1900mm |
|
|
Machine weight |
1800KGS |
|
Standard Features
 |
 |
 |
| Box loader | Seal | Tissue paper conveyor |
Standard Features
|
|
|
| Box loader | Seal | Tissue paper conveyor |
